Additional information
| Product Type | P2 with Standoff |
|---|---|
| Data Sheet | https://downloads.cree-led.com/files/ds/h/HB-C513A-WSN-WSS-MSN-MSS.pdf |
| Product Family | HB C5xx |
| Sub-App-Portable | Consumer |
| Product Status | Active |
| Voltage Class | 3 |
| Color | White |
| Viewing Angle | 55° |
| Color Spec Type | CCT (K) |
| Color Spec Min | 2500 |
| Color Spec Max | 4600 |
| CRI Options | 80 |
| Optical Char | — |
| Current Binning | 0.020 |
| Temp Binning | 25 |
| Vf Typical | 3.2 |
| Power Typical | 0.1 |
| Optical Units | mcd |
| Optical Bin Typ | 5400 |
| Optical Bin Min | 3000 |
| Current Max | 0.030 |
| Power Max | 0.1 |
| Ingress Protection | N/A |
| Physical Units | mm |
| X | 5 |
| Y | 5 |
