HB Through-Hole LEDs

Cree LED’s through-hole LEDs deliver industry leadership performance for traditional signage and video display applications. With numerous firsts and innovations since their introduction, these LEDs remain the preferred choice for their high-grade materials, environmental stability and intensity.

These lamps are made with an advanced optical-grade epoxy that offers superior high-temperature and high-moisture resistance performance in outdoor signal and sign applications.

Screen Master® 4-mm & 5-mm oval LEDs: matched horizontal radiation patterns that are optimized for full-color video screens, digital billboards and passenger-information signs
White & single-color P2 LEDs: wide variety of beam angles available to address many applications

HB LEDs Feature Sheet

Specifications

Product Type	Product	Data Sheet	Product Status	Color	Beam Angle	Color Spec Type	Color Min	Color Max	Binning Current (A)	Typ Intensity (mcd)	Max Current (A)	Footprint X (mm)	Footprint Y (mm)
P2 with Standoff	C4SMA-BGY		Active Active	Blue	90°/45°	DWL (nm)	465	475	0.01	900	0.035	3.9	3
P2 with Standoff	C4SMA-GGY		Active Active	Green	90°/45°	DWL (nm)	520	540	0.01	2500	0.035	3.9	3
P2 with Standoff	C4SMA-RGY		Active Active	Red	90°/45°	DWL (nm)	619	624	0.015	1500	0.05	3.9	3
P2 with Standoff	C4SMB-AGY		Active Active	Amber	90°/45°	DWL (nm)	584	596	0.02	2400	0.05	3.9	3
P2 with Standoff	C4SMB-BGY		Active Active	Blue	90°/45°	DWL (nm)	460	475	0.02	1400	0.035	3.9	3
P2 with Standoff	C4SMB-GGY		Active Active	Green	90°/45°	DWL (nm)	520	540	0.02	7500	0.035	3.9	3
P2 with Standoff	C4SMB-RGY		Active Active	Red	90°/45°	DWL (nm)	619	624	0.02	2800	0.05	3.9	3
P2 with Standoff	C4SMM-BJY		Active Active	Blue	115°/65°	DWL (nm)	460	475	0.01	380	0.035	3.9	3
P2 with Standoff	C4SMM-GJY		Active Active	Green	115°/65°	DWL (nm)	520	540	0.01	1800	0.035	3.9	3
P2 with Standoff	C4SMM-RJY		Active Active	Red	110°/60°	DWL (nm)	619	624	0.015	1050	0.05	3.9	3
P2 No Standoff	C503B-AAN		Active Active	Amber	15° min	DWL (nm)	584	596	0.02	15000	0.05	5	5
P2 No Standoff	C503B-AAN		Active Active	Amber	15°	DWL (nm)	584	596	0.02	13000	0.05	5	5
P2 with Standoff	C503B-AAS		Active Active	Amber	15° min	DWL (nm)	584	596	0.02	15000	0.05	5	5
P2 with Standoff	C503B-AAS		Active Active	Amber	15°	DWL (nm)	584	596	0.02	13000	0.05	5	5
P2 No Standoff	C503B-ABN		Active Active	Amber	23°	DWL (nm)	584	596	0.02	5000	0.05	5	5
P2 with Standoff	C503B-ABS		Active Active	Amber	23°	DWL (nm)	584	596	0.02	5000	0.05	5	5
P2 No Standoff	C503B-ACN		Active Active	Amber	30°	DWL (nm)	584	596	0.02	6000	0.05	5	5
P2 No Standoff	C503B-ACN		Active Active	Amber	30° min	DWL (nm)	584	596	0.02	6800	0.05	5	5
P2 with Standoff	C503B-ACS		Active Active	Amber	30°	DWL (nm)	584	596	0.02	6000	0.05	5	5
P2 with Standoff	C503B-ACS		Active Active	Amber	30° min	DWL (nm)	584	596	0.02	6800	0.05	5	5

Documentation

	Version	Last Updated
C5SMF-Rxx,Gxx,Bxx,C5SME-Rxx:Screen Master® 5-mm Oval LEDs	5	30 Mar 2022
Screen Master® 4-mm Oval LEDs: S4SMS-RJY/GJY/BJY	1	03 Mar 2020
CP41B-WES/WGS: P4 White LEDs	7	26 Jan 2022
CP41B-RxS, CP41B-AxS: P4 Red & Amber LEDs	4	17 Dec 2019
CP41A-PxS: P4 Orange LEDs	3	18 Dec 2019
CP41A-RxS, CP41A-AxS: P4 Red & Amber LEDs	6	18 Dec 2019
Screen Master® 5-mm Oval LEDs: C5SMF-AJF/AJE	2	26 Jan 2022
C566D-Rxx,Gxx,Bxx,Axx:Screen Master® 5-mm Oval LEDs	5	14 Oct 2019
Screen Master® 5-mm Oval LEDs: C566C-RFF/RFE/AFF/AFE	4	28 Oct 2021
C543A-WMN: 5-mm Round White LED	7	01 Mar 2019
C535A-WJx [Data Sheet]	3	27 Nov 2023
C513A-WSS/WSN/MSS/MSN: 5-mm Round White LEDs	9	01 Mar 2019
C503C-WAS/WAN: 5-mm Round White LEDs	11	26 Feb 2019
C512A-WNS/WNN: 5-mm Round White LEDs	7	01 Mar 2019
Screen Master® 4-mm Oval LEDs: C4SMA-RGY/GGY/BGY	3	21 May 2021
C503C-Rxx, C503C-Axx: 5-mm Round Red & Amber LEDs	2	14 Oct 2019
C503B-WAN: 5-mm Round White LED	10	26 Feb 2019
C503B-Bxx, C503B-Gxx: 5-mm Round Blue & Green LEDs	7	26 Jan 2022
C503B-Bxx, C503B-Gxx: 5-mm Round Blue & Green LEDs	2	14 Oct 2019
C503B-BAS/BAN/GAS/GAN, 5-mm Blue and Green Round LED	5	14 Oct 2019

	Version	Last Updated
High Brightness LEDs	11	30 Nov 2023
LED Products and Application Guide	10	09 Oct 2023

	Version	Last Updated
High-Brightness LED Soldering & Handling	34	03 Aug 2023
High Brightness LED Lamp Reliability Test Standards	8	27 Mar 2023

	Version	Last Updated
3D STEP Models – All High Brightness LEDs		01 Sep 2023

	Version	Last Updated
High Brightness 4mm Oval Green Series LEDs RoHS Declaration		09 Aug 2022
High Brightness 4mm Oval Blue Series LEDs RoHS Declaration		09 Aug 2022
High Brightness 4mm Oval Red Series LEDs RoHS Declaration		09 Aug 2022
High Brightness 5mm Oval Color Series LEDs RoHS Declaration		09 Aug 2022
High Brightness 5mm Oval Red Series LEDs RoHS Declaration		09 Aug 2022
High Brightness 5mm Round White Series LEDs RoHS Declaration		09 Aug 2022
High Brightness 5mm Round Red Series LEDs RoHS Declaration		09 Aug 2022
4mm Oval Green [REACH]	235	17 Aug 2023
5mm Round White, Blue & Green [REACH]	235	17 Aug 2023
5mm Round Amber & Red [REACH]	235	17 Aug 2023
5mm Oval Red [REACH]	235	17 Aug 2023
5mm Oval Blue & Green [REACH]	235	17 Aug 2023
4mm Oval Red [REACH]	235	17 Aug 2023
4mm Oval Blue [REACH]	235	17 Aug 2023
CP41 Amber & Red [REACH]	235	17 Aug 2023

	Version	Last Updated
4mm Oval Green [REACH]	235	17 Aug 2023
5mm Round White, Blue & Green [REACH]	235	17 Aug 2023
5mm Round Amber & Red [REACH]	235	17 Aug 2023
5mm Oval Red [REACH]	235	17 Aug 2023
5mm Oval Blue & Green [REACH]	235	17 Aug 2023
4mm Oval Red [REACH]	235	17 Aug 2023
4mm Oval Blue [REACH]	235	17 Aug 2023
CP41 Amber & Red [REACH]	235	17 Aug 2023

	Version	Last Updated
CreeLED, Inc. Sales Terms & Conditions		17 Apr 2023
CreeLED Shanghai Electronics Limited Sales Terms and Conditions		17 Apr 2023
CreeLED Hong Kong Limited Sales Terms & Conditions		17 Apr 2023
CreeLED Shanghai Electronics Limited – Shenzhen Branch Sales Terms & Conditions		17 Apr 2023
