XLamp® XD/XQ LEDs

XLamp XD & XQ 1.6 mm footprint LEDs span a wide range of design options, from the high reliability ceramic mid-power XQ-A family up to the extreme lumen density XD16 family. XLamp XQ family LEDs are optimized for outdoor architectural lighting and emergency vehicle lighting applications where precise optical control must be achieved in the smallest possible physical space. XLamp XD16 LEDs are optimized for maximum lumen density and easily outperform chip-scale-package (CSP) LEDs in LED array applications.

1.6 x 1.6 mm footprint
Single LED die per package for best optical control
Proven reliability in harsh environment outdoor and transportation lighting applications

Latest Innovations

XLamp XQ-E HD & HI LEDs: higher max current of 1.500A
XLamp XQ-E HD & HI LEDs: new colors (Cyan, PC Cyan and PC Lime) and white options (2200K & 1800K CCTs)

Specifications

Product Type	Product	Product Status	Color	Optical Characteristics	Color Spec Type	Color Min	Color Max	CRI Options	Binning Current (A)	Binning Temp (°C)	Typical Vf	Max Current (A)	Max Power (W)
SMD Ceramic	XD16 Premium White	New New	White	High Intensity	CCT (K)	2200	7000	70, 80, 90	0.35	85	2.73	2	6
SMD Ceramic	XD16 Standard	Active Active	White	---	CCT (K)	2200	7000	70, 80, 90	0.35	85	2.73	2	6
SMD Ceramic	XQ-A	Active Active	PC Blue	---	PC	---	---	---	0.175	25	3.25	0.25	1
SMD Ceramic	XQ-A	Active Active	Red	---	DWL (nm)	620	630	---	0.175	25	2.2	0.25	1
SMD Ceramic	XQ-A	Active Active	Red-Orange	---	DWL (nm)	610	620	---	0.175	25	2.2	0.25	1
SMD Ceramic	XQ-A	Active Active	PC Amber	---	PC	---	---	---	0.175	25	3.4	0.25	1
SMD Ceramic	XQ-A	Active Active	Green	---	DWL (nm)	520	535	---	0.175	25	3.1	0.25	1
SMD Ceramic	XQ-A	Active Active	Blue	---	DWL (nm)	465	485	---	0.175	25	3.15	0.25	1
SMD Ceramic	XQ-A	Active Active	White	---	CCT (K)	2700	6500	70, 80, 90	0.175	85	3	0.3	1
SMD Ceramic	XQ-E HD	Active Active	Red-Orange	High Density	DWL (nm)	610	620	---	0.35	25	2.18	1.5	5
SMD Ceramic	XQ-E HD	New New	Cyan	High Density	DWL (nm)	490	510	---	0.35	25	2.65	1.5	5
SMD Ceramic	XQ-E HD	New New	PC Lime	High Density	PC	---	---	---	0.35	25	2.8	1.5	5
SMD Ceramic	XQ-E HD	New New	PC Cyan	High Density	PC	---	---	---	0.35	25	2.8	1.5	5
SMD Ceramic	XQ-E HD	Active Active	White	High Density	CCT (K)	1800	6500	70, 80, 90	0.35	85	2.8	1.5	5
SMD Ceramic	XQ-E HD	Active Active	Royal	High Density	DWL (nm)	450	465	---	0.35	25	2.9	1.5	5
SMD Ceramic	XQ-E HD	Active Active	Blue	High Density	DWL (nm)	465	485	---	0.35	25	2.8	1.5	5
SMD Ceramic	XQ-E HD	Active Active	Green	High Density	DWL (nm)	520	535	---	0.35	25	2.65	1.5	5
SMD Ceramic	XQ-E HD	Active Active	PC Amber	High Density	PC	---	---	---	0.35	25	2.9	1.5	5
SMD Ceramic	XQ-E HD	Active Active	Red	High Density	DWL (nm)	620	630	---	0.35	25	2.18	1.5	5
SMD Ceramic	XQ-E HD	Active Active	Photo Red	High Density	PWL (nm)	650	670	---	0.35	25	2	1.5	5

Documentation

	Version	Last Updated
XLamp® XQ-E Plus Data Sheet	0	11 Oct 2023
XLamp® XD16 Premium White Data Sheet	3	05 May 2023
XLamp® XD16 Data Sheet	5	05 May 2023
XLamp® XQ-A Data Sheet	9	05 May 2023
XLamp® XQ-E Data Sheet	18	30 Nov 2023

	Version	Last Updated
XLamp® White LEDs [Feature Sheet]	34	17 Jul 2023
Color LED Portfolio [Feature Sheet]	21	07 Apr 2023
XLamp® Portable LEDs [Feature Sheet]	8	06 Apr 2023
LED Products and Application Guide	10	09 Oct 2023

	Version	Last Updated
Cree LED XLamp® Components IES LM-80 Testing Results	85	01 Dec 2023
XLamp® LED Eye Safety	41	02 Oct 2023
XLamp® XD16 LEDs Soldering & Handling	3	09 Jun 2023
XLamp® LEDs Solder Joint Reliability Study	4	11 May 2023
JESD51-14 Thermal Resistance Calculation Method	1	19 Apr 2023
XLamp® Pick and Place Application Note	3	20 Apr 2023
Avoidance of Ceramic-Substrate-Based LED Chip Cracking Induced by PCB Bending or Flexing	2	19 Apr 2023
XLamp® LED Reliability Overview	6	20 Apr 2023
XLamp® LED Long-Term Lumen Maintenance	4	20 Apr 2023
XLamp® LED Electrical Overstress	4	20 Apr 2023
Optimizing PCB Thermal Performance for XLamp® XQ & XH Family LEDs	2	21 Apr 2023
Thermal Management of XLamp® LEDs	5	21 Apr 2023
Solder-Point Temperature Measurement of XLamp® LEDs	3	19 Apr 2023
XLamp® LEDs Testing and Characterization	3	19 Apr 2023
XLamp® LEDs Chemical Compatibility	9	20 Apr 2023
XLamp® XQ Family Soldering & Handling	8	06 Oct 2023
XLamp® HD Discrete LED Design Guide	2	17 Apr 2023

	Version	Last Updated
XQ-E HI Cyan [Optical Model]	2451
XQ-E Plus HI PC Amber [Optical Model]	1505
XQ-E Plus HI Green [Optical Model]	1780
XQ-E Plus HI Blue [Optical Model]	1628
XQ-E Plus HD Royal Blue [Optical Model]	1693
XQ-E Plus HD PC Amber [Optical Model]	1500
XQ-E Plus HD Green [Optical Model]	1634
XQ-E Plus HD Blue [Optical Model]	1627
XQ-E HD PC Amber (Post PCN 5257) [Optical Model]	1687	03 Feb 2022
XQ-E HI Royal Blue [Optical Model]	1192
XQ-E HI Red/Red-Orange [Optical Model]
XQ-E HI Green [Optical Model]	1181
XQ-A Blue (Post PCN 5263) [Optical Model]	1714
XQ-E HI Blue [Optical Model]	1160
XQ-E HD Royal Blue [Optical Model]	1162
XQ-E HD Red/Red-Orange [Optical Model]	1098
XQ-E HD Green [Optical Model]	1310
XQ-E HD Blue [Optical Model]	1251
XQ-A Red [Optical Model]		02 Jan 2019
XQ-E HI PC Amber (Post PCN 5257) [Optical Model]	1787	03 Feb 2022

	Version	Last Updated
XQ-E Plus HD White [Optical Model]	1596
XQ-E Plus HI White [Optical Model]	1515
XD16 Standard Cool White [Optical Model]	624
XD16 Standard Warm White [Optical Model]	623
XD16 Premium Neutral White [Optical Model]	1507
XD16 Premium Cool White [Optical Model]	1836
XD16 Premium Warm White [Optical Model]	1837
XQ-E HI Warm White [Optical Model]	1155
XQ-A Cool White (Post PCN 5263) [Optical Model]	1584
XQ-E HD Cool White [Optical Model]	1087
XQ-E HD Warm White [Optical Model]	1086
XQ-E HI Cool White [Optical Model]	1157

	Version	Last Updated
3D STEP Models – All XLamp® LEDs		01 Sep 2023
XQ Family Metal Core Gerber Information
XQ family Star Board Gerber

	Version	Last Updated
XQ-E HD Others [RoHS]		08 Sep 2022
XQ-E HD Red/Red-Orange/Photo Red [RoHS]		08 Sep 2022
XD16 [RoHS]		18 Feb 2022
XQ-E HI Others [RoHS]		18 Feb 2022
XQ-E HI Red/Red-Orange [RoHS]		18 Feb 2022
XQ-A Others [RoHS]		12 Aug 2021
XQ-A Red/Red-Orange [RoHS]		08 Sep 2022

	Version	Last Updated
XLamp XD16 Standard & Premium White [REACH]	235	31 Aug 2023
XLamp XQ-E HI Red-Orange, Red [REACH]	235	31 Aug 2023
XLamp XQ-E HD Red-Orange, Red, Photo Red [REACH]	235	31 Aug 2023
XLamp XQ-E HI White, Royal Blue, Blue, Green, PC Amber [REACH]	235	31 Aug 2023
XLamp XQ-E HD White, Royal Blue, Blue, Green, PC Amber [REACH]	235	31 Aug 2023
XLamp XQ-A Red-Orange, Red [REACH]	235	31 Aug 2023
XLamp XQ-A White, Blue, Green, PC Amber [REACH]	235	31 Aug 2023

	Version	Last Updated
CreeLED, Inc. Sales Terms & Conditions		17 Apr 2023
CreeLED Shanghai Electronics Limited Sales Terms and Conditions		17 Apr 2023
CreeLED Hong Kong Limited Sales Terms & Conditions		17 Apr 2023
CreeLED Shanghai Electronics Limited – Shenzhen Branch Sales Terms & Conditions		17 Apr 2023
