Additional information
| Product Type | COB Metal |
|---|---|
| Data Sheet | https://assets.cree-led.com/a/ds/x/XLamp-CMA3090.pdf |
| Product Family | COB Metal |
| Product Status | Active |
| LES | 23 |
| Voltage Class | 48 |
| Color | White |
| Viewing Angle | 115° |
| Color Spec Type | CCT (K) |
| Color Spec Min | 2200 |
| Color Spec Max | 6500 |
| CRI Options | 70, 80, 90, 95 |
| Optical Char | Fidelity, Specialty, Standard |
| Current Binning | 1.8 |
| Temp Binning | 85 |
| Vf Typical | 45 |
| Power Typical | 81 |
| Optical Units | Lm |
| Typ Lm 4000K-70 | 13925 |
| Typ LPW 4000K-70 | 172 |
| Typ Lm 3000K-80 | 11720 |
| Typ LPW 3000K-80 | 145 |
| Typ Lm 3000K-90 | 9909 |
| Typ LPW 3000K-90 | 122 |
| Max Lm 3000K-80 | 20244 |
| Max Flux | 23828 |
| Current Max | 3.6 |
| Power Max | 174 |
| Ingress Protection | N/A |
| Physical Units | mm |
| X | 27.35 |
| Y | 27.35 |
