Additional information
| Product Type | LED Chip |
|---|---|
| Data Sheet | https://assets.cree-led.com/a/ds/c/Chips-EZ1950-p.pdf |
| Product Family | Chips EZ-p |
| Product Status | Active |
| Voltage Class | 3 |
| Color | Royal |
| Color Spec Type | DWL (nm) |
| Color Spec Min | 445 |
| Color Spec Max | 465 |
| CRI Options | — |
| Optical Char | — |
| Current Binning | 0.700 |
| Temp Binning | 25 |
| Vf Typical | 3.05 |
| Vf Max | 3.6 |
| Power Typical | 2 |
| ESD | 250V |
| Optical Units | mW |
| Optical Bin Min | 1120 |
| Current Max | 3.000 |
| Conductive Epoxy | Optional |
| Clear Epoxy | Not Recommended |
| Eutectic Attach | Recommended |
| Ingress Protection | N/A |
| Orientation | p-up, Vertical |
| Physical Units | µm |
| X | 1940 |
| Y | 1940 |
