Additional information
| Product Type | L2 Linear |
|---|---|
| Data Sheet | https://downloads.cree-led.com/files/ds/l2/L2-VB192-VB256.pdf |
| Product Family | L2 VB |
| Product Status | New |
| Voltage Class | 48 |
| Color | White |
| Viewing Angle | 120° |
| Color Spec Type | CCT (K) |
| Color Spec Min | 3000 |
| Color Spec Max | 5000 |
| CRI Options | 80, 90 |
| Optical Char | — |
| Current Binning | 2.000 |
| Temp Binning | 50 |
| Vf Typical | 44 |
| Power Typical | 88 |
| Optical Units | Lm |
| Typ Lm 4000K-80 | 17101 |
| Typ LPW 4000K-80 | 194 |
| Typ Lm 3000K-80 | 16051 |
| Typ LPW 3000K-80 | 182 |
| Typ Lm 3000K-90 | 13670 |
| Typ LPW 3000K-90 | 155 |
| Current Max | 3.840 |
| Power Max | 176 |
| Physical Units | mm |
| X | 1120 |
| Y | 20 |
| Footprint Type | N/A |
| LED Count | 256 |
| Populated LED | 2835 3V J Class |
