Additional information
| Product Type | SMD Ceramic |
|---|---|
| Data Sheet | https://downloads.cree-led.com/files/ds/x/XLamp-XPG4.pdf |
| Product Family | XLamp XP |
| Sub-App-Auto | Aftermarket/EVL |
| Sub-App-Indoor | High Density |
| Sub-App-Portable | Beam Distance |
| Product Status | New |
| LES | 2 |
| Voltage Class | 3 |
| Color | White |
| Viewing Angle | 125° |
| Color Spec Type | CCT (K) |
| Color Spec Min | 2700 |
| Color Spec Max | 7000 |
| CRI Options | <70, 70, 80, 90 |
| Optical Char | High Intensity |
| Current Binning | 0.700 |
| Temp Binning | 85 |
| Vf Typical | 2.8 |
| Power Typical | 2 |
| Optical Units | Lm |
| Max Flux | 1017 |
| Current Max | 3.000 |
| Power Max | 10 |
| Physical Units | mm |
| X | 3.45 |
| Y | 3.45 |
