J Series® 5050 LEDs
J Series 5050 LEDs deliver high efficacy and long lifetimes to high-output indoor & outdoor lighting applications. Cree LED’s 5050 product family offers numerous advantages over competing 5050s, including superior intensity through secondary optics, better color-over-angle and leading corrosion resistance.
- 6500K – 2700K CCTs on every 5050
- 70, 80 & 90 CRI on every 5050
- Reported L90 & Q90 lifetimes > 109k hrs (5050A/5050B)
- Widest range of voltage options
- Cree LED’s top-tier global IP indemnification
Latest Innovations
- JR5050C E Class LEDs offer the industry’s highest efficacy at 228 LPW typical at 4000K, 70 CRI, 1W
- JK5050B H Class LEDs deliver optimized efficacy at 1-2W in the square LES 5050B package, delivering 223 LPW typical at 4000K, 70 CRI, 1W
Specifications
No Products Found
| Product Type | Product | Data Sheet | Product Status | Color | LES (mm) | Voltage Class | CCT Min (K) | CCT Max (K) | CRI Options | Binning Current (A) | Typ Vf | Typ lm @ 4000K, 70 CRI | Typ LPW @ 4000K, 70 CRI | Max Current (A) | Max Power (W) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| SMD White Body |
JK5050B H Class
 |
|
New New | White | 7 | 6 | 2200 | 6500 | 70, 80, 90 | 0.180 | 5.54 | 223 | 224 | 1.000 | 6 |
| SMD White Body |
JK5050B H Class
|
|
New New | White | 7 | 24 | 2200 | 6500 | 70, 80, 90 | 0.045 | 22.16 | 223 | 224 | 0.250 | 6 |
| SMD White Body |
JR5050 P Class
 |
|
Active Active | White | 4.5 | 6 | 2700 | 6500 | 70, 80, 90 | 0.400 | 5.77 | 442 | 192 | 1.000 | 6 |
| SMD White Body |
JR5050 P Class
|
|
Active Active | White | 4.5 | 9 | 2700 | 6500 | 70, 80, 90 | 0.260 | 8.56 | 434 | 195 | 0.660 | 6 |
| SMD White Body |
JR5050 P Class
|
|
Active Active | White | 4.5 | 24 | 2700 | 6500 | 70, 80, 90 | 0.100 | 23.08 | 442 | 192 | 0.240 | 6 |
| SMD White Body |
JR5050 Q Class
|
|
Active Active | White | 4.5 | 6 | 2700 | 6500 | 70, 80, 90 | 0.400 | 5.8 | 425 | 183 | 1.000 | 6 |
| SMD White Body |
JR5050 Q Class
|
|
Active Active | White | 4.5 | 9 | 2700 | 6500 | 70, 80, 90 | 0.260 | 8.6 | 415 | 186 | 0.660 | 6 |
| SMD White Body |
JR5050 Q Class
|
|
Active Active | White | 4.5 | 24 | 2700 | 6500 | 70, 80, 90 | 0.100 | 23.5 | 430 | 183 | 0.240 | 6 |
| SMD White Body |
JR5050 Q Class
|
|
Active Active | White | 4.5 | 36 | 2700 | 6500 | 70, 80, 90 | 0.065 | 34.5 | 415 | 185 | 0.165 | 6 |
| SMD White Body |
JR5050B K Class
 |
|
Active Active | White | 7 | 6 | 2700 | 6500 | 70, 80, 90 | 0.400 | 5.67 | 455 | 201 | 1.000 | 6 |
| SMD White Body |
JR5050B K Class
 |
|
Active Active | White | 7 | 30 | 2700 | 6500 | 70, 80, 90 | 0.080 | 28.35 | 455 | 201 | 0.240 | 6 |
| SMD White Body |
JR5050C E Class
 |
|
New New | White | 7 | 6 | 2200 | 6500 | 70, 80, 90 | 0.400 | 5.63 | 480 | 213 | 1.000 | 6 |
